PowerBOX 125amp 1PH+N+E 230V 19” RACK BOX HE6U 6 x 32A 1PH+N+E 230V
Our No: 11873
Manufacturer No:
| Units | % | Price per unit |
|---|---|---|
| 2 | 7.5% | £1015.65 |
£1,098.00
£1,317.60 (inc VAT)
125A 1P+N+E 230V 6U Power Distro with 6 x 32A 2P+E 230v
- Efficient and reliable 19" AC mains distribution
- Cases made from 3mm extruded aluminum fronts and steel back boxes
- Ring wired in 2.50mm Tri-Rated cable using crimped bootlace ferrules
- All distros have C Class (high current inrush) miniature circuit breakers (MCBs)
- Layout:
- FRONT: Incoming 125Amp 1P+N+E 230v Appliance Inlet
- Main Protection: Circuit Breaker 125A MCB Type C
- Outgoing Protection:
- 6 x Individual 32A MCBs and status neons
- REAR:
- 6 x 32A 2P+E Commando Sockets IP44
- 2 Per Phase
- Depth inc. front Ceeforms 300mm
- Installed accessories:
- 1 single-phase led 1M Din (IN, 1 fuse switch 1p 10x38mm 1M Din),
- 1 earth stud.
- Technical data:
- IEC 61439-1 & 2 / PSC, Un 230V 1PH+N+E, fn 50Hz
- InA 125amp, Icc 6.000A, RDF 40/100,
- IP2X, Electrical insulation class I (first).
